1500VA Rack Mount UPS

Furman proudly introduces the F1500-UPS: battery backup designed exclusively for audio/video professionals and home theater aficionados.

For decades, traditional audio/video components were simple analog devices designed to easily weather power outages of well over two seconds. Later, as computer and microprocessor based components gained in popularity, their extraordinary sensitivity to even a fraction of a second’s power loss was managed with traditional UPS (uninterruptible power supply) technology.

Unfortunately, these units were solely designed for the I.T. professional. Though they included many technologies and features appropriate to that application, they fell short for premium audio/video components. Though many of these manufactures later recognized the ever-emerging professional audio/video, broadcast, and home theater market, their lack of experience led merely to a re-tooled chassis. These hastily produced UPS devices lacked the technologies necessary to truly optimize protection, performance, and control for today’s audio video components.

The Furman F1500-UPS more than fills this void, and offers your system unparalleled battery back-up technology, created from the ground up to meet the exacting demands of the world’s most sensitive audio, video and control systems!

Features

• Voltage: 85 - 137 VAC • Frequency: 57 - 63 Hz • AC Power: • Surge Protection: Non-sacrifical SMP (Series Multi-Stage Protection) • Current Rating: 12 A • Over-voltage Shutoff, fast rise: 150 ± 5V • Over-voltage Shutoff, slow rise: 140 ± 5V • Noise Attenuation: 10 dB @ 10kHz, 40 dB @ 100 kHz, 50 dB @ 500kHz • Linear Attenuation: From 0.05 - 100 Ohms line impedance • Automatic Voltage Regulation, Sensitive Mode Capture Range: 96 - 135V • >Automatic Voltage Regulation, Sensitive Mode Output Range: 120V ± 5%

• >Automatic Voltage Regulation, Standard Mode Capture Range: 93 - 142V • >Automatic Voltage Regulation, Standard Mode Output Range: 120V ± 10% • UPS Output: • Voltage: 120 ± 5V True Sine Wave • Frequency: 60 Hz ± 1% • UPS Output Capacity: 1500VA, 900W @ 0.6pf • UPS Backup Time: 12 minutes at full-load, 32 minutes half-load • Transfer Time: < 4ms • UPS Output: • Dimensions: 17” W (19” w/ rack ears) x 19.2” D x 3.5” H • Weight: 72 lbs.

Details

The following components are ideal for use with the F1500-UPS: DAWs Satellite Receivers Cable Boxes Digital Video Recorders Media Servers External Hard Drives Digital Mixing Consoles Lamp Based Video Displays Control Systems For power management of other components, Furman recommends Classic or Prestige Series Power Conditioners. For high-current components such as power amplifiers and powered subwoofers, solutions featuring Furman’s exclusive Power Factor Technology are ideal. Approximate Run Time, 1500VA ** Satellite Reciever or Cable Box = 80 Minutes Control System + Media Server = 40 Minutes Digital Mixing Console (24 channel) = 20 minutes DAW Computer + Digital I/O + External Hard Drive + 24” LCD Monitor = 7 minutes These run times should be used as a guideline only and are dependant on device and usage.
