CX 2-Channel Series Power Amplifier, 500 W/ch @ 4 ohms

The CX502 is designed to meet the specialized needs of sound contractors and with high output power, versatile loading options, high thermal capacity and reliability, the CX502 is the ideal solution to any permanently installed sound system. The new CX amplifier is equipped with many contactor specific features including 1 dB detented gain controls for easily repeatable settings and a custom security cover for tamper-proof installations. Active inrush limiting eliminates AC inrush current, cutting the need for power sequencers. This CX amplifier also includes an HD15 Data Port connector to interface with QSControl, QSC's computer-controlled audio system, that allowes remote amplifier monitoring and control via a standard Ethernet network.

Features

• Exclusive PowerLight switch-mode power supply technology for high performance and compact size. • Custom integrated security cover for tamper proof installations. • Variable speed fan for low noise. • 1 dB detented gain controls for fast and accurate gain settings. • Active inrush limiting eliminates AC inrush current, removing the need for expensive power sequencers. • XLR and detachable Euro style input connectors. • HD15 DataPort connector for QSControl computer control or signal processing accessories. • Dip switch control for clip limiters, high pass filters, bridge mono and parallel operation. • Selectable high pass filters protect speakers and prevent speaker transformer saturation withminimal effect on program material (33 Hz or 75 Hz on non-V models, 50 Hz or 75 Hz on V models).

• Comprehensive front panel indicators including signal, clip, protect and QSC's exclusive bridge mono and parallel input LEDs. • Barrier strip output connector. • Comprehensive protection circuitry including DC, infrasonic, thermal overload and short circuit protection. • Class H complementary bipolar output circuitry for high efficiency (CX702, CX902, CX1102 & CX1202V). • Optional external transformer accessory pack for isolated 70 and 100 -volt outputs (converts CX302 to 400 watts per channel isolated output). • Compact size - all models only 2 RU and 14" deep for reduced rack cost and floor space. • 3-year warranty plus optional 3-year extended service contract. • Light weight - all models only 21 pounds (9.5 kg)
