CM2204 4 Channel Power Amplifier, 220 Watts @ 8 ohms/70V

CM Series power amps include multiple protection circuits, such as ACL Active Clip Limiting, which automatically reduces gain at the onset of clipping to prevent amplifier and load damage; IGM Instantaneous Gain Modulation, which monitors load current to protect against overloading; AUTORAMP to prevent abrupt turn-on levels by gradually increasing gain when the amplifier is switched on; as well as short circuit, DC voltage, comprehensive thermal management, current in-rush turn on/off transient and sub/ultrasonic input.

A switch allows selection of 0.775V sensitivity or x40 gain. A high pass filter is selectable per channel, and 100 Volt and 50 Volt operation is supported with our CM100V and CM50V accessories.

Features

• Power into 4 Ohm - 150 W x 4 • Power into 8 Ohm - 220 W x 4 • Power @ 70V - 220 W x 4 • Multi-load architecture allows low impedance or 70 Volt operation without select switch (100 or 50 Volt output operation with CMx accessory) • Low mains current draw • Compact design allows up to 8 channels in a 2U rack space • Low weight • Cost-effective for many multi-channel applications • Flexible configuration

• Easy set-up • CM Series Protection Circuits • ACL™ (Active Clip Limiting) automatically reduces gain at the onset of clipping to prevent amplifier and load damage • IGM™ (Instantaneous Gain Modulation) monitors load current to protect against overloading • AUTORAMP™ gradually increases gain when the amplifier is turned on, preventing abrupt turn-on level • Other protection features include: short circuit, DC voltage, comprehensive thermal management, current in-rush turnon/off transient and sub/ultrasonic input • Five-year warranty • Dimensions (W x H x D): 19" x 3.5" x 16.69" (483 x 89 x 424 mm) • Weight: 34 lbs. (16 kg)
