CX 8-Channel Series Power Amplifier, 100W/ch @ 70 Volts

The QSC CX108V CX 8-Channel Series Power Amplifier, 100-Watts into - 8 Channels at 70 Volts, 3-Pin Euro-Style Detachable Blocks, 1 dB Detented Gain Controls, Variable Speed Fan, Active Inrush Limiting, On/Off Muting, 2-Rack Space.

This CX108V Amplifier is designed for permanently installed sound systems where rackspace is at a premium. The 8-channel CX108V features DataPorts for remote amplifier management or signal processing, incorporate QSC's legendary PowerLight® technology delivers unmatched reputation for quality and reliability. PowerLight is a revolutionary switching power supply technology that provides ample current to the audio power circuitry by charging the supply rails 230,000 times per second through an ultra-low noise impedance circuit.

8 channels, 100 watts/ch at 70V

Features

• 100 watts per channel at 70 volts. •  Compact size - only two rack spaces and 14" deep for reduced rack space. •  Channel pairs bridgeable for maximum flexibility. •  Exclusive PowerLight switch-mode power supply technology for high performance and compact size. •  Active Inrush Limiting eliminates AC inrush current, removing the need for expensive power sequencers. •  Four HD15 DataPorts (one per channel pair) for QSControl computer control or QSC's signal processing accessories. •  Custom integrated gain control security cover for tamper-proof installations. •  1 dB recessed detented gain controls for fast and accurate settings.

•  Detachable Euro style input and output connectors. •  DIP switch control for clip limiters, high-pass filters, bridge mono and parallel operation. •  Selectable high-pass filters protect speakers and prevent speaker transformer saturation with minimal effect on program material. •  Comprehensive front panel indicators including signal, clip, bridge mono and parallel input LEDs. •  Fully protected - including DC, infrasonic and ultrasonic, thermal overload and short circuit protection. •  High-performance Class AB+B complementary bipolar output circuitry. •  3-year warranty plus optional 3-year extended service contract. •  Light weight - only 21 pounds (9.5 kg) for easier racking and shipping.

Details
